Woodfast PT410A Planer Thicknesser

• Following the outstanding market success of the PT310A 12″ Planer Thicknesser, WOODFAST GROUP AUSTRALIA has decided to launch the heavy-duty PT410A.

  This impressive machine, weighing in at 365kg and available in either 3kw (4HP) 1 Phase or 4kw (5.3HP) 3 Phase. The true Helical Style / Spiral Head cutter block is 70mm in diameter with 72 carbide 4 sided knives and offers a full 410mm of superb wood jointing and thickness capacity. The helical cutter block reduces noise and presents a superior finish to traditional straight blades.

  With the convenience of a single-handed table lift (no need to remove the fence), switching from surface planning to thickness cannot be easier. This versatile machine features an extra-large aluminium extruded fence with centered controls and cam locking for quick adjustments. In Jointer mode, the table length is 1659mm. The added Thicknesser Outfeed Extension Table (standard) gives extra support for those longer, heavy boards.

  It’s a great machine to choose for serious woodworkers and busy trade workshops.

  Features:

  • Spiral Head Cutter Block for better thickness result and longer knife life and less noise
  • Single-Handed Table Lift (no need to lift the fence), switching from surface planing to thickness cannot be easier
  • Centered controls and CAM locking for quick adjustments
  • Built-in dust chute and capable of handling both planning and thickness operations

the Woodfast PT410A Planer Thicknesser, a robust 16″ (410 mm) dual-purpose woodworking machine designed for serious woodworkers and busy trade workshops:

Capacity & Power

• Cutting width: 410 mm (16″)

• Thicknessing height range: 4 mm to 225 mm

• Feed rate: 7 m/min

Motor Options

• Single-phase (230 V, 4 HP / 3 kW)

• Three-phase (400–415 V, 5.3 HP / 4 kW)

Cutter Block

• Spiral (helical) head, 70 mm diameter, with 72 four-sided carbide knives

• Offers quieter operation, smoother finish, and longer knife life compared to straight blades

Construction & Handling

• Weighs approx. 265 kg (net), 303–365 kg gross depending on the source

• Includes single-handed table lift, so you don’t need to remove the fence when switching between planer and thicknesser modes

• Centred controls and cam-locking fence adjustment for swift, accurate setup

Table & Support

• In jointer/planer mode: table length is approximately 1,659 mm

• Additional optional outfeed support table included for handling long stock

• Integrated dust chute, 100–125 mm outlet depending on variant

Dimensions & Transport

• Footprint: around 1.7 m × 0.68 m × 1.13 m (L×W×H)
